BEFORE YOU ADD TO CART

Important: To fully utilize the W2U thruster's capabilities on iPhones prior to the iPhone 15, an additional Lightning port Apple camera kit with external power supply is required due to power limitations on these devices. W2U only comes with Type C OTG cable in the retail package.

Sale price$494.50 SGD

Tax excluded. Shipping calculated at checkout

Pickup available at Jaben @ The Adelphi

Usually ready in 24 hours

Luxury Precision W2 Ultra

Luxury Precision W2 Ultra

Jaben @ The Adelphi

Pickup available, usually ready in 24 hours

1 Coleman St, #01-25
The Adelphi
Singapore 179803
Singapore

+6563370809

W2U "The Extraordinary"

  • 800mW+800mW Continuous High Power Output! L&P's New High-Power Dongle W2 Ultra.


Extra-small Size

  • [Pint-sized like a piece of chewing gum. The body weighs only 26g. Being light is essential for portable devices.]


Extremely Powerful

  • The circuitry, wiring, power supply, copper foil, and amp have all been redesigned, with actual power reaching up to 800mW. Built-in custom large aluminum heat sink ensures continuous 800mW output, not just peak bursts.

Exceptionally Innovative

  • [As a learning] from E7 research and development, the voltage of the amp power supply is adjustable: ±4.5V for in-ear, 6V for over-ear. Exclusive firmware optimized for HD800 and flagship [full sized] headphones in high power mode.
  • Exemplary Sound Tuning
    Return of the classic sound tuning of the W2 series, retaining the original CS43131 chip "L&P tuning." While output power doubles and peaks, it still maintains "0" background noise for low-impedance, high-sensitivity IEMs.EQ for various usages and special tuning for headphones, suitable for different tastes and styles.

What Makes W2U Extraordinary?

  • Everything.
    Apart from retaining the same DAC and FPGA as W2, everything else is different:
    - Extraordinary Circuit Design: Fully optimized circuit layout and power design.
    - Extraordinary Output Power: Continuous output of 800mW @ 320.
    - Extraordinary Tuning: Unique firmware tuning for HD800 and flagship large headphones.
    Extraordinary Power Supply: Dual-stage amp power supply voltage of ±4.5V/±6V, offering both long battery life and high power.
    - Extraordinary Cooling Design: Custom large CNC aluminum heat sink + carbon fiber backplate.
    - Extraordinary Experience: New design style with unique color schemes and single-button knob operation.
Luxury Precision W2 Ultra
Luxury Precision W2 Ultra Sale price$494.50 SGD
Specifications

Basic parameters

  • Product model W2 Ultra
  • Color/Size/Weight GREEN/63x24x12.5mm/26g
  • Display 0.91 inches monochrome OLED
  • Packages list
    Manual x1/warranty card x1/C-C cable x1/TYPEA-C adapterx1
  • SNR
    - 3.5mm:129db (A Weighting)
    -4.4mm:133db (A Weighting)
  • Dynamic Range
    -3.5mm:129db(A Weighting)
    -4.4mm:133db(A Weighting)
  • THD+N
    - 3.5mm:0.00048%@32 Ohms
    - 4.4mm:0.00012% @300 Ohms
    Output power
    - 3.5mm:216mW@32 Ohms
    - 4.4mm:800mW@32 OhmsOhms
    Output voltage
    - 3.5mm:2.65Vrms

    DAC
    CS43131x2
    Input ports
    Type-C USB female


    4.4mm:5.3V
    Output ports
    3.5mm SE (PO、 SPDIF) 4.4mm balanced
    Sampling Rate PCM 16/24/32 bit 44.1 KHz-384KHz Sampling Rate DSD
    Native DSD64/Native DSD128/Native DSD256
    Supported systems IOS/OS/Android/Windows/linux
    Function Parameter
    EQ Normal/CLASS/JAZZ/ROCK/POP/BASS/MOVIE/GAME
    NORMAL/IER-M9/IER-Z1R/SE846/IE800S/Xelento
    SDF Tone tuning IE600/IE900/Traillii Ti/N500S/HD800/Utopia
    Gain HIGH/LOW
    Digital Filter FAST/SLOW/NOS/LL FAST/LL SLOW
    HID Key Supported
    SPDIF output Supported
    Firmware upgrade Supported
    LP TUNE
    TUNE 01/ TUNE 02
    PA voltage adjust ±4.5V / ±6V
