iBasso DX240

Features:-

>Flagship ES9038 Pro DAC chip.

>Supports high-resolution 32-Bit/768kHz PCM and Native DSD512 decoding.

>Full 16x MQA decoding.

>Swappable AMP module design with support for existing AMP1-AMP8.

>Comes stock with AMP1 MK3 module.

>Self-developed FPGA Master technology.

>Dual independent NDK femtosecond crystal oscillators.

>Sharp 5” 1080P Full HD display.

>High-speed USB 3.1 connector.

>Lightning-Fast Snapdragon 660 SoC.

>4GB RAM.

>64GB ROM.

>Up to 2TB MicroSD card slot.

>Coaxial output support.

>Bluetooth V5.0 connectivity.

>Dual Band WiFi(2.4GHz/5GHz).

>Dual OS, Mango OS & Open Android 9.0.

>Up to 11 hours of continuous music playback.

Technical Specs:-

>Stock amp module: AMP1 MK3.

>Output ports: 2.5mm TRRS, 3.5mm Single-ended, 3.5mm Line Out.

>Display: 5.0” 1080P Full HD.

>Battery capacity: 4400mAh.

>Charging time: 2.5H.

>Playback time: up to 11 hours.

Output Parameters(2.5mm Bal):-

>Maximum output level: 6.2Vrms.

>Power: 878mW@32Ω, 128mW@300Ω.

>Frequency response: 10Hz-45kHz.

>SNR: 125dB.

>DNR: 125dB.

>THD+N: -114dB.

>Resolution: -119dB.

>Output Impedance: 0.57Ω.

Output Parameters(3.5mm Single-ended):-

>Maximum output level: 3.1Vrms.

>Power: 281mW@32Ω, 32mW@300Ω.

>Frequency Response: 10Hz-45kHz.

>SNR: 123dB.

>DNR: 123dB.

>THD+N: -110dB.

>Resolution: -117dB.

>Output Impedance: 0.38Ω.
