iBasso DX320 MAX TI

Installment option available at check out page

Package Content

For those who like it loud: DX320 Max TI goes up to 11. But iBasso Audio's trans-portable music player also knows how to play soft as well – a stepped resistor analog volume control preserves the resolution of four ROHM BD34301EKV DACs at any listening level.

  • -  Limited to 888 units worldwide, individually numbered units - FINAL SALE
    -  Features iBasso's in-house developed stepped attenuator for delicate IEM listening at realistically lower volume
    -  Class A amplification with 8.4 Volts
    -  5.0" IPS screen (1080x1920), with On-Cell capacitive touch panel
    -  Quad (x4) BD34301EKV ROHM DAC Chips
    -  The highest level of build and component quality

  • The digital and analog sections of the DX320MAX are powered separately, with each having an independent charging system. The digital and analog hardware and signal communications, adopt optocouplers and I2C isolators to completely isolate the digital to analog sections from any interference.

    The AMP section is powered by a true +/- 8.4V battery pack. No voltage boost is used, which ensures the highest purity and current output. An optimized super class A discrete amp circuit, which eliminates the switching distortion of transistors, while providing the sound signature of a class A amplifier, that also significantly reduces heat generation, is used.

    A custom analog 4-wiper stepped attenuator that has less than +/-0.1dB channel tolerance imbalance, has been selected. 4 settings for the physical gain control. 5.0" IPS screen (1080x1920), with On Cell capacitive touch panel. Quad BD34301EKV ROHM DAC Chips are incorporated.

  • 14nm Octa-Core Qualcomm Snapdragon 660 SoC

    6GB LPDDR4X + 128GB ROM

    FPGA-Master, a dedicated control of the audio system

    (x4) ROHM BD34301EKV DACs

    (x2) Accusilicon ultra-low phase noise Femtosecond oscillators

    Support of QC3.0 and PD3.0 quick charge for the digital section

    Support of SDXC and SDHC Micro SD cards up to and including 2TB

    Android 11 + Mango OS

    Bit for Bit playback with support up to 32bit/768kHz
    Support of Native DSD up to and including 512x
    USB digital output that outputs up to PCM 32bit/384kHz, Native DSD256, and DoP DSD128
    Audio Formats Supported: MQA, APE, FLAC, WAV, WMA, AAC, ALAC, AIFF, OGG, MP3, DFF, DSF, and DXD

    3.5mm single ended up to 4.5V RMS
    4.4mm balanced output is up to 9V RMS
    Mini coaxial output that supports up to 24bit/384kHz and DoP DSD128
    Support for 2.4G & 5G WiFi, Bluetooth 5.0

    Support USB3.1 Superspeed transfer
    USB DAC function that supports up to 32bit/384kHz and DoP DSD128
    17 hours play time in normal mode and 13 hours in the Ultimate mode

  • TBA
